A container house is a movable and reusable building product, also known as a "container-style house". This type of housing uses modular design and prefabricated production in a factory, with the basic unit being a box. It can be used alone or combined horizontally and vertically to form spacious living spaces. The vertical direction can be stacked up to three layers. The unit structure of the box is a standard component made of special steel welded using special techniques. The boxes are connected to each other with bolts, and the structure is stable and easy to install, making it popular with many users.

Introduction to Products

In some special industries, such as mining and oil industry, the construction site environment is relatively harsh, and there has always been a demand influenced by the construction features. After the house is delivered to the site, it can be used without installation. As the project progresses, the house can be moved as a whole to another location. Due to the need for overall lifting and moving, the overall rigidity of the house is required to be higher, and the corresponding processing technology is required to be more strict. The cost of manufacturing such houses is relatively high, so its development has been relatively slow. In recent years, with the rapid growth of economic level, the development of such houses has also had a qualitative leap.

(01) Modularization

Because the length, width and height of this kind of house are fixed dimensions, so that several fixed functional layout can be set, according to different use requirements, between the houses of each function

It can be flexibly combined to make it a standardized product and mass production is possible.

(02) Highly integrated

There is no need for secondary decoration on site, and the lifting position can be moved in.

(03) Overall movement

The site can be moved as a whole without disassembly, greatly reducing the cost of secondary utilization of the site.

(04) Low transportation cost

In order to adapt to the long distance shipping, the box house will be divided into roof, ground, column, plate several parts, several houses can be packaged as a whole into a container volume of independent packaging directly for ocean transportation, saving a lot of transportation costs.

Description of design

Purpose of use

(01)  High-end demand for temporary construction products at construction sites, such as office, accommodation and conference rooms for project managers;

(02)  The construction site is limited by the site, can only install box combination room products;

(03)  Field operation room; Such as: field exploration and construction mobile office, dormitory, etc.

(04)  Emergency room; Such as: military mobile command center, emergency mobile command center, disaster relief mobile command center, etc.

Introduction of features

(01)  Convenient transportation, especially suitable for frequent replacement of construction sites;

(02)  Strong and durable, all composed of steel, with strong seismic, deformation resistance;

(03)  Good sealing performance, strict manufacturing process makes this mobile room has good watertightness;

(04)  The activity room based on the standard steel chassis, can derive a lot of combination space. Such as conference room, dormitory, kitchen, toilet and so on. The standard width is 2.4 meters, the height is 2.2 meters, and the length is 4 meters to 12 meters.

(05)  Convenient disassembly, superior performance, stable and firm, good shock resistance, waterproof, fireproof and anticorrosive, light weight. The house is an integral structure with frames and walls of color steel composite panels, which can be migrated as a whole. The service life can reach more than 20 years, which is suitable for duty rooms, guard rooms, shops and so on.

Layout of scene

Selection and matching
